Specifications of KOYO Bearing 51315
Specifications
(Boundary dimensions …etc)
- d
- 75 mm
- D
- 135 mm
- T
- 44 mm
- r(min.)
- 1.5 mm
- Basic load ratings Ca
- 192 kN
- Basic load ratings C0a
- 339 kN
- Fatigue load limit : Cu
- 15.0 kN
- Limiting speeds(Grease lub.)
- 1200 min-1
- Limiting speeds(Oil lub.)
- 1900 min-1
- d1(max.)
- 135 mm
- D1(min.)
- 77 mm
- D2
- – mm
- D3
- – mm
- A
- – mm
- R
- – mm
- C
- – mm
Mounting dimensions
- da(min.)
- 111 mm
- Da(max.)
- 99 mm
- ra(max.)
- 1.5 mm
Refer.
- (Refer.)Mass
- 2.68 kg
