Specifications of SKF Bearing 15101/15245
| Dimension series | 15000 |
Dimensions
| d | 25.4mm | Bore diameter |
| D | 62.0mm | Outside diameter |
| T | 19.05mm | Total width |
| d1 | 45.8mm | Shoulder diameter of inner ring |
| B | 20.638mm | Width of inner ring |
| C | 14.288mm | Width of outer ring |
| r1,2 | 0.8mm | Chamfer dimension of inner ring |
| r3,4 | 1.3mm | Chamfer dimension of outer ring |
| a | 12.68mm | Distance side face to pressure point |
Abutment dimensions
| da | 38.0mm | Diameter of shaft abutment |
| db | 32.0mm | Diameter of shaft abutment |
| Da | 54.0mm | Diameter of housing abutment |
| Da | 55.5mm | Diameter of housing abutment |
| Db | 58.0mm | Diameter of housing abutment |
| Ca | 4.0mm | Minimum width of space required in housing on large side face |
| Cb | 4.5mm | Minimum width of space required in housing on small side face |
| ra | 0.8mm | Radius of shaft fillet |
| rb | 1.3mm | Radius of housing fillet |
Calculation data
| Basic dynamic load rating | C | 59.5kN |
| Basic static load rating | C0 | 57.0kN |
| Fatigue load limit | Pu | 6.2kN |
| Reference speed | 9000.0r/min | |
| Limiting speed | 11000.0r/min | |
| Limiting value | e | 0.35 |
| Axial load factor | Y | 1.7 |
| Axial load factor | Y0 | 0.9 |
Mass
| Mass | 0.3kg |
