Specifications of SKF Bearing 32006 X
| Dimension series | 4CC |
Dimensions
| d | 30.0mm | Bore diameter |
| D | 55.0mm | Outside diameter |
| T | 17.0mm | Total width |
| d1 | 43.6mm | Shoulder diameter of inner ring |
| B | 17.0mm | Width of inner ring |
| C | 13.0mm | Width of outer ring |
| r1,2 | 1.0mm | Chamfer dimension of inner ring |
| r3,4 | 1.0mm | Chamfer dimension of outer ring |
| a | 13.165mm | Distance side face to pressure point |
Abutment dimensions
| da | 36.0mm | Diameter of shaft abutment |
| db | 37.0mm | Diameter of shaft abutment |
| Da | 48.0mm | Diameter of housing abutment |
| Da | 49.0mm | Diameter of housing abutment |
| Db | 52.0mm | Diameter of housing abutment |
| Ca | 3.0mm | Minimum width of space required in housing on large side face |
| Cb | 4.0mm | Minimum width of space required in housing on small side face |
| ra | 1.0mm | Radius of shaft fillet |
| rb | 1.0mm | Radius of housing fillet |
Calculation data
| Basic dynamic load rating | C | 43.9kN |
| Basic static load rating | C0 | 44.0kN |
| Fatigue load limit | Pu | 4.55kN |
| Reference speed | 10000.0r/min | |
| Limiting speed | 12000.0r/min | |
| Limiting value | e | 0.43 |
| Axial load factor | Y | 1.4 |
| Axial load factor | Y0 | 0.8 |
Mass
| Mass | 0.17kg |
