Specifications of SKF Bearing 32019 X
| Dimension series | 4CC |
Dimensions
| d | 95.0mm | Bore diameter |
| D | 145.0mm | Outside diameter |
| T | 32.0mm | Total width |
| d1 | 120.7mm | Shoulder diameter of inner ring |
| B | 32.0mm | Width of inner ring |
| C | 24.0mm | Width of outer ring |
| r1,2 | 2.0mm | Chamfer dimension of inner ring |
| r3,4 | 1.5mm | Chamfer dimension of outer ring |
| a | 31.113mm | Distance side face to pressure point |
Abutment dimensions
| da | 106.0mm | Diameter of shaft abutment |
| db | 106.0mm | Diameter of shaft abutment |
| Da | 130.0mm | Diameter of housing abutment |
| Da | 136.0mm | Diameter of housing abutment |
| Db | 140.0mm | Diameter of housing abutment |
| Ca | 6.0mm | Minimum width of space required in housing on large side face |
| Cb | 8.0mm | Minimum width of space required in housing on small side face |
| ra | 2.0mm | Radius of shaft fillet |
| rb | 1.5mm | Radius of housing fillet |
Calculation data
| Basic dynamic load rating | C | 206.0kN |
| Basic static load rating | C0 | 270.0kN |
| Fatigue load limit | Pu | 30.5kN |
| Reference speed | 3400.0r/min | |
| Limiting speed | 4300.0r/min | |
| Limiting value | e | 0.44 |
| Axial load factor | Y | 1.35 |
| Axial load factor | Y0 | 0.8 |
Mass
| Mass | 1.85kg |
