Specifications of SKF Bearing 395 A/394 A
| Dimension series | 395 |
Dimensions
| d | 66.675mm | Bore diameter |
| D | 110.0mm | Outside diameter |
| T | 22.0mm | Total width |
| d1 | 86.55mm | Shoulder diameter of inner ring |
| B | 21.996mm | Width of inner ring |
| C | 18.824mm | Width of outer ring |
| r1,2 | 0.8mm | Chamfer dimension of inner ring |
| r3,4 | 1.3mm | Chamfer dimension of outer ring |
| a | 20.871mm | Distance side face to pressure point |
Abutment dimensions
| da | 77.0mm | Diameter of shaft abutment |
| db | 74.5mm | Diameter of shaft abutment |
| Da | 98.0mm | Diameter of housing abutment |
| Da | 102.0mm | Diameter of housing abutment |
| Db | 105.0mm | Diameter of housing abutment |
| Ca | 4.0mm | Minimum width of space required in housing on large side face |
| Cb | 3.0mm | Minimum width of space required in housing on small side face |
| ra | 0.8mm | Radius of shaft fillet |
| rb | 1.3mm | Radius of housing fillet |
Calculation data
| Basic dynamic load rating | C | 108.0kN |
| Basic static load rating | C0 | 118.0kN |
| Fatigue load limit | Pu | 13.4kN |
| Reference speed | 4800.0r/min | |
| Limiting speed | 6000.0r/min | |
| Limiting value | e | 0.4 |
| Axial load factor | Y | 1.5 |
| Axial load factor | Y0 | 0.8 |
Mass
| Mass | 0.79kg |
