Specifications of SKF Bearing NU 1048 ML
Dimensions
| d | 240.0mm | Bore diameter |
| D | 360.0mm | Outside diameter |
| B | 56.0mm | Width |
| D1 | 316.2mm | Shoulder diameter of outer ring |
| F | 270.0mm | Chamfer dimension of loose flange ring |
| r1,2 | 3.0mm | Chamfer dimension |
| r3,4 | 3.0mm | Chamfer dimension |
| s | 7.5mm | Permissible axial displacement |
Abutment dimensions
| da | 252.0mm | Diameter of spacer sleeve |
| da | 266.0mm | Diameter of spacer sleeve |
| db | 274.0mm | Diameter of shaft abutment |
| Da | 348.0mm | Diameter of housing abutment |
| ra | 2.5mm | Radius of fillet |
| rb | 2.5mm | Radius of fillet |
Calculation data
| Basic dynamic load rating | C | 600.0kN |
| Basic static load rating | C0 | 800.0kN |
| Fatigue load limit | Pu | 78.0kN |
| Reference speed | 2000.0r/min | |
| Limiting speed | 3000.0r/min | |
| Minimum load factor | kr | 0.15 |
| Limiting value | e | 0.2 |
| Axial load factor | Y | 0.6 |
Mass
| Mass | 19.7kg |
Associated products
| Angle ring | HJ 1048 |
