TIMKEN Bearing NCF1840V

Single-row, full-complement cylindrical roller bearings.Features include integral flanges on the inner and outer rings.Can manage axial loads in one direction and small axial displacement.The radial internal clearance (RIC) for the bearing assembly must be included when ordering the complete assembly.
Material: Bearing steels
In Stock:
Photo may not represent actual item. See the technical specification for details.

Specifications of TIMKEN Bearing NCF1840V

TIMKEN Bearing NCF1840V

Specifications

Bore d

200 mm

Static Load Rating Co

337000 N75700 lbf

Dynamic Load Rating C11

188000 N42400 lbf

Dimension S2

1.80 mm0.071 in

Geometry Factor Cg3

0.1460

Thermal Speed Ratings – Oil

740 rpm

Thermal Speed Ratings – Grease

610 rpm

Weight

2.5 Kg5.6 lb

Bearing Dimensions

O.D. D

250 mm9.8425 in

Width B

24 mm0.9449 in

DUR/DOR F/E

237.5 mm9.3504 in

Mounting Data

Chamfer rsmin

1.5 mm0.06 in

Chamfer r1smin4

1.1 mm0.040 in

Backing Shaft Diameter ds

211.5 mm8.3300 in

Backing Housing Diameter Ds

238.5 mm9.3900 in
